Material | FR4 |
Board Thickness | 1.6mm |
Copper Thickness | 1/1 |
Cover Film | green |
Silkscreen Color | White |
Surface Technics | ENIG (1-3u |
Min Holes | 0.2mm |
Min Line space and width | 6/6mil |
Update Time | 2019-12-07 |
Detail Information
SENYAN main SMT production line consists of automated high-precision state-of-the-art equipments from Panasonic,Samsung,Japan total 6 lines(Smallest SMT components size can reach to 0201,capable of 0.6mm*0.3mm~50mm gap,+/-0.05 accuracy),Daily capacity can reach to 11,000,000 components.
Electronic Assembly Made capacity
Item
|
Capability
|
Item
|
Capability
|
Solder PastePrintig
|
Accuracy:±0.025mm
|
Wave Soldering
|
Nitrogen source:external
|
Max. speed:150mm/sec | Speed:5in² /sec (60FOV/sec) | ||
PCB max. area:400*310mm | Temperature accuracy:±1°C | ||
PCB thickness:0.2-6mm | Lead free compatible | ||
SMT | Accuracy:±0.03mm | AOI | Accuracy:±0.0024mm |
Speed:0.17sec/pc | Speed:5in² /sec (60FOV/sec) | ||
PCB max. area:350*350mm | PCB max. area:300*300mm | ||
Available part:0201 chip to 35*35mm | Available component:0201 chip and fine pitch | ||
Accuracy:±0.05mm | |||
PCB max. area:350*350mm | X-ray,Inspection | BGA void(0.5mm distance between Ball) | |
Available part:0402 chips to 14mm (H 12mm) | |||
Minimum SMD resistor and capacitor:0201 | Solderability inner shielding | ||
Minimum BGA R-VTx:0.15mm | BGA Rework | Nitrogen source:NA | |
Nitrogen source:external | PCB max. size:350mm | ||
Reflow Soldering | Nitrogen source:external | Temperature accuracy:±1°C | |
PCB max. size:400*330mm | |||
Temperature accuracy:±4°C | Lead free compatible |
